Allen & Heath AHM32 32x32 Audio Matrix Processor
Description
With 32 zone outputs, echo cancelling and audio networking options, AHM-32 is ideal for multi-room installations in hospitality, corporate and education environments.
Processing
Sound Management Tools
• 4x Automatic Mic Mixers
• ANC (Ambient Noise Compensation)
• Priority Ducking
• 8-band PEQ, dynamics and delay on every input and zone
• Speaker processing with x-over filter, delay, limiter, PEQ and All-Pass Filters
• NTP support
• EQ Ganging (Relative, Absolute, and Mirrored Controls)
Hardware
Always In Control
In addition to remote controllers, GPIO and 3rd party integration, AHM-32 has a front panel screen and 8x programmable SoftKeys for intuitive volume control, source select, preset recall and more.
Key Features:
• 32×32 Processing Matrix
• 12×12 Local Analogue I/O
• I/O Port for Audio Networking (Up to 128×128)
• Dante 96kHz Option Card (AES67 and DDM ready)
• SLink 128×128 Option Card for Audio Expansion
• 32 Configurable Processing Outputs – Mono / Stereo Zones or Speaker Processing
• 96kHz FPGA Core With Ultra-low Latency
• Front Panel Screen and Navigation
• 8x SoftKeys
• Compatible With IP1, IP6, IP8 Remote Controllers
• 2×2 Local GPIO Plus Networkable GPIO Interface
• TCP/IP Protocol for Third Party Integration
• Crestron, AMX and Extron Drivers
• Mac / Windows System Manager Software
• Custom Control app and Editor for BYOD
• 16 User Profiles
• Integrated Stereo Playback
Event Scheduler
